Smeg KSEC61NE3 Universale Under-cabinet hood cm. 60 - black

Smeg KSEC61NE3 under-cabinet hood - cm. 60 - black

Typology
Family: Cappa
Type: Integrated in view
Hood width: 60 cm
Filtering: Aspirating / Filtering (for the filtering version, the KITFC111 carbon filter must be purchased separately from the Accessories)
EAN Code: 8017709343323

Aesthetics
Color: Black
Aesthetics: Universal
Design: With exposed front panel
Material: Painted Material

Programs / Functions
No. of speeds: 3

Commands
Controls adjustment: Slider

Technical Features
No. of lights: 2
Light Type: LED
Light power: 4W
Light Color Temperature (°K): 4000 °K
Maximum suction capacity in free mode (P0): 315 m³/h
Motor power: 115W
No. of filters: 1
Grease filters: Multilayer metallic
Carbon filters: Yes
Minimum installation distance from gas hob: 650 mm
Minimum installation distance from electric hob: 450 mm
Motor inlet diameter: 120 mm

Performance / Energy Label
Energy efficiency class (EEC): C
Fluid Dynamic Efficiency Class (FDEC): E
Grease filtering efficiency class (GFEC): G
Lighting efficiency class (LEC): E
Annual Energy Efficiency (AEC): 60 kWh/a
Fluid Dynamic Efficiency (FDE): 10
Illuminance efficiency (LE): 11 lux/W
Grease filtering efficiency (GFE): 40%
Air flow at minimum speed (Qmin): 170 m³/h
Air flow at maximum speed (Qmax): 305 m³/h
Weighted acoustic power emission at minimum speed (SPEmin): 58 dB(A)
Weighted acoustic power emission at maximum speed (SPEmax): 72 dB(A)
Time Gain Factor (F): 1.6
Energy efficiency index: 84.8
Air flow rate measured in maximum efficiency condition (Qbep): 167 m³/h
Air pressure measured at maximum efficiency condition (Pbep): 198 Pa
Electrical power absorbed in maximum efficiency condition (Wbep): 92 W
Rated power of the lighting system (WL): 8 W
Average illumination of the hob lighting system (Emiddle): 90 lux
Sound level in highest configuration (Lwa): 72 dB(A)

Electrical Connection
Electrical connection rating: 133 W
Voltage: 220-240V
Frequency: 50 Hz
Power cable length: 1500 mm

Speed ​​1
Suction capacity (IEC 61591): 170 m³/h
Noise level (IEC 60704-2-13): 58 dB(A)
Power: 85W

Speed ​​2
Suction capacity (IEC 61591): 240 m³/h
Noise level (IEC 60704-2-13): 66 dB(A)
Power: 95W

Speed ​​3
Suction capacity (IEC 61591): 305 m³/h
Noise level (IEC 60704-2-13): 72 dB(A)
Power: 115W

Logistics Information
Product dimensions (mm): 150x598x490
Width: 598 mm
Product depth (mm): 490 mm
Product Height (mm): 150 mm
Net weight (kg): 7,550 kg
Gross weight (kg): 8,550 kg

Optional accessories (purchasable separately in the dedicated section at the bottom of the page)
- KITFC111 Round activated carbon filter​ 1 piece KIT

Grease filters
The grease filters purify the air from cooking grease. They are easily removable for periodic cleaning.

Light
The hood is equipped with LED lamps. The light can be turned on independently of the suction fan and thus allow the work surface to be illuminated.
